10” Rigid Carbon-Glass Fiber Honeycomb
Cone and durable Rubber Surround
Aluminum Die-cast Basket.
Stress-free Spider
delivers smooth and strong bass sound
with long-lasting reliability.
Large magnet and Optimized Yoke
reproduces deep low frequencies.
| Type | Volume | W | H | D1 | D2 | Mounting Hole | Port Diameter d | Port Length I | Displacement |
|---|---|---|---|---|---|---|---|---|---|
| SEALED | 0.6 cu.ft (17.0L) |
28-1/4" 718mm |
12-3/4" 324mm |
4-1/16" 103mm |
6-5/16" 160mm |
9-1/4" 235mm |
- | - | 0.039 cu.ft (1.110L) |
| PORTED | 3"(76mm) | 11"(280mm) |
Enclosure Volume and Frequency Response graphs are measured from 9/16 inch MDF.
| Subwoofer | 10" (250mm) |
|---|---|
| Cone | Carbon-Glass Fiber Honeycomb Cone |
| Nominal Impedance | 4Ω |
| Peak Input Power | 1000W |
| Rated Input Power | 250W |
| Sensitivity | 90 dB/W at 1m |
| Free Air Resonance | 39Hz |
| Frequency Response | 35-800Hz |
| Mounting Depth | 3-3/8" (85mm) |
| Recommended Sealed and Ported Box Volume | 0.6 cft (17.0L) |
| Weight of Magnet | 2.38lbs(1080g) |
| Net Weight | 10.36lbs(4700g) |
| SYMBOL | UNIT | VALUE | |
|---|---|---|---|
| Nominal Impedance | Z | Ω | 4 |
| DC Resistance | Revc | Ω | 3 |
| Voice Coil Inductance | Levc | mH | 2.1 |
| Piston Area | Sd | sq.m | 0.034 |
| Force Factor | BL | Tm | 10.7 |
| Volume Acoustic Compllance | VAS | liter | 21.05 |
| cu.ft | 0.744 | ||
| Moving Mass | Mms | 9 | 127.0 |
| Resonance Frequency | Fs | Hz | 38.6 |
| Mechanical Q Factor | Qms | 5.279 | |
| Electrical Q Factor | Qes | 0.84 | |
| Total Q Factor | Qts | 0.72 | |
| Peak Excusion | Xmas | mm | 7.5 |
| Displacement | cc | 1110 | |
| cu.ft | 0.039 | ||
| Mounting Depth | in.(mm) | 3-3/8 (85) | |
| Weight of Magnet | lbs(g) | 2.38(1080) | |
| Net Weight | lbs(g) | 10.36(4700) | |
| Voice Coil Diameter | in.(mm) | 1-15/16 (50) |
