AB-Class, 70W x 4ch
Hi-Performance Amplifier
(Discontinued)
(1) A better cooling system with fan
(2) 45mm large toroidal transformer,
Secondary Capacitor 9900uF and Primary Capacitor 6600uF ensure solid performance
(3) One-side Terminals for Easier Installation
Speaker-level Input with Signal Sensing Turn-On
| Amplifier Tech-Spec | KAC-PS704EX |
|---|---|
| Maximum Output Power | 1000W |
| RMS Power at 4ohms | 70W x 4ch |
| RMS Power at 2ohms | 100W x 4ch |
| Bridged at 4ohms | 200W x 2ch |
| Frequency Response | 20Hz - 50kHz |
| High Pass Filter | 80Hz, -12dB/oct |
| Low Pass Filter | 50Hz – 200Hz, -24dB/oct |
| Speaker Level Input | Yes |
| Signal to Noise Ratio | 100dB |
| Dimensions W x D x H (mm) | 335 x 204 x 56 |
