TS-890SFront / Rear Panel

Front Panel

  • ① [PHONES] Jack (φ6.3): For Connecting Headphones
  • ② [PADDLE] Jack (φ6.3) : For Connecting CW Operation Paddle
  • ③ [USB-A] Connector: For USB Memory, USB Keyboard
  • ④ [MIC] Connector (8 Pin Metal Type):For Connecting Microphone

Back Panel

  • ① [ANT 1, ANT 2] Antenna Connectors (M-type)×2
  • ② [AT] Connector (6 Pin): For Connecting External Antenna Tuner
  • ③ [RX IN] Connector (RCA): For Connecting Receive Only Antenna
  • ④ [RX OUT] Connector (RCA): For Connecting External Receiver
  • ⑤ [DRV] Connector (RCA): Drive Output
  • ⑥ [ANT OUT] Connector: For Antenna Signal Distribution to External Receiver
  • ⑦ [DC13.8V] Connector (4 Pin): For Connection of DC Power Source
  • ⑧ [REF IN(10MHz)] Connector (BNC): For Standard External Signal Input
  • ⑨ [KEYPAD] Jack(φ3.5): For Connection of External PF Key
  • ⑩ [COM] Connector(D-SUB 9 Pin: For PC Control
  • ⑪ [USB-A] Connector: For USB Memory, Keyboard
  • ⑫ [GND] Terminal: For Connection of Earth
  • ⑬ [KEY] Jack(φ6.3): For Paddle, Straight Key, and PC Keying
  • ⑭ [ACC2] Connector(13Pin DIN): For Connection of Audio I/O and Other Accessories
  • ⑮ [REMOTE] Connector(7Pin DIN):For Connection of Linear Amplifier
  • ⑯ [METER] Jack(φ3.5):For Connection of Commercial Analog Meters
  • ⑰ [EXT.SP] Jack(φ3.5):For Connection of External Speakers
  • ⑱ [USB-B] Connector:For PC Control, USB Audio
  • ⑲ [DISPLAY] Connector(DVI-I):For Connection of External Display
  • ⑳ [LAN] Connector(RJ-45):For PC Control (KNS)

Dimensions
